- Place of Origin:CN;GUA
- Material:Brass
- Brand Name:COVNA latching solenoid valve
- Model Number:HK07 latching solenoid valve
- Power:Solenoid
- Pressure:Medium Pressure
- Application:General
- Port Size:1/8'"-2"
- Standard or Nonstandard:Standard
- Media:Water
- Temperature of Media:High Temperature
- Structure:Latching
magnetic pulse solenoid valve
| Body material | Wrought brass |
| Seal material | NBR |
| Connection type | Thread |
| Pressure range | 0.5-10Bar |
| Structure type | Pilot type |
| Interface size | 13-50mm |
| temperature range | 0-60 degree centigrades |
| Optional voltage | AC220V, AC24V, AC380V,AC110V,DC24V,DC12V, 50/60HZ |
Introduction
This series valve is famous for sensitive reaction and high pressure,
Usually be used to circuit control board connection, it is good for energy saving,
Widely used to IC card gas combustion meter, water saving irrigation, water meter
and various automatic flushing of sanitary ware.
The core of the valve can be pulled and stretched to be the good shape, with
good strictness, credibility, sensitive reaction and long life.
Using Conduction
Fluid Medium: Water, Gas (but not corrosive)
Fluids Temperature: ≤60℃, please use at the area,
Which relative temperature can’t over than 85%
How to use
To exchange the poles of the battery for on-off
Standard technical parameters
Body
Interface size: 3/8-2’’
Flow diameter: 13-50mm
Body material: Wrought brass
Connection type: G thread
Pressure class: 0.5-10bar
Structure type: Pilot type
Control type: Normally closed
Components
Seal material: NBR
Medium temperature: 0℃-60℃
Ambient temperature: 0℃-70℃
Install way: According to the body tag to install, in order to enhance
the valve service life, better coil upward, horizontal installation;
Coil voltage: DC24V/12V, other voltage can be customized
Pipe Size | Flow Diameter (mm) | Working Pressure Range (Kgf/cm2) | The Max. Temperature ℃ | Outline dimension
| Model |
Length × Width × Height | |||||
3/8” | 10 |
0.5-10 |
60 | 66×48×83 | HK07-10 |
1/2” | 15 | 66×48×83 | HK07-15 | ||
3/4” | 20 | 75×58×88 | HK07-20 | ||
1” | 25 | 96×70×101 | HK07-25 | ||
11/4” | 35 | 131×96×116 | HK07-32 | ||
11/2” | 40 |
|
| 131×96×116 | HK07-40 |
2” | 50 | 165×120×142 | HK0-50 |
Warranty: Great Quality Products
We stand behind the quality of our products 100%. All of our items come with a warranty to give you a peace of mind.
New Guaranteed: All of our items are in BRAND NEW condition in OEM or Original Packaging. Orders are packaged with care to make sure your items arrive in perfect condition.
Shipping Terms:
1.We ship most of orders within 1-3 business day after receiving your payment(for sample).
2.We will post tracking number by e-mail after processing your order.
3. We provide combine shipping if you have multiple orders. In order to get combine shipping price, please send us a combine shipping request.
This company produces the [solenoid valve] and [pneumatic valve] has been widely used in machine automation design, such as water level control, temperature control, air conditioner, automatic filling equipment, fire control, professional irrigation, the SPA massage (SPA), steam dipping, solar water heating engineering, water treatment and environmental protection equipment, chemical industry machine food machine, etc.
latching solenoid valve
1.18 months warranty
Great quality products
We stand behind the quality of our products 100%
All of our items come with a warranty to give you a peace of mind.
New Guaranteed: All of our items are in new condition in OEM or Original packing.
2.MOQ There is no MOQ for COVNA design but for cusomer's, the MOQ according your design to
decide.we will offer the free sample for the massive products
3.Package
Our package method is in perfect condition, or according customized.
4.Delivery
Shipment term: CIF/CFR/FOB Shenzhen China, EXW Dongguan China
Shipment date: 7-30 days after receiving the deposit
We will ship your items by sea, by air(DHL,UPS,FedEx,TNT, EMS,ARAMEX)
Payment
We usually accept T/T(wire transfer), Western Union.
Trade Currency: USD or RMB.
TT 30% deposit in advance,70% balance paid before shipment.
(sample order) T/T / Western union 100% at sight.
latching solenoid valve
latching solenoid valve
Q1: What is the Warranty for the solenoid valves?
A1: For the valves,we have one and half year warranty.If any quality problems on our side occured in this period ,we will make replacement.
Q2:What is NO and NC?
A2: NO stands for normally open, that is , valve keeps open without power.If connect it with power, the valve will get closed.NC stands for normally closed,that is valve keeps closed without power.If connect it with power, the valve will get open.
Q3: What is the assembly way of solenoid valves?
A.3 we suggest to make horizontal installation to enlarge life time,but it can be vertical installation if have special request.
Q4:Is there cheap shipping cost to import to our country?
A4: For small order,express will be best.And for bulk order,sea ship way is best but take much time. For urgent orders,we suggest to ship by air.
Q5:Can we make customized product?
A5: Yes, we are good at making customized products.More than 30% of our products are customized products. We have successfully customized for customer from various fields from USA,Norway.Australia, Germany ect.
Q6: Why choose us? Any advantages?
A6: The answer is Yes. There are5 advantages.
(1) MUTUAL BENEFIT: Our offer will be reasonable, our price will be cheaper in the same quality.
(2) CUSTOMIZED SERVICE: We can make the product as your request, Shape and Quality can meet your request.
(3) OEM: (1)Laser Print your Logo (≥10PCS). (2)Design your packing box(≥100PCS).
(4) MIX ORDER: We accept mix order, different model and small quantity order.
(5) AFTER SERVICE: (1)1.5Years Guarantee. (2)If some parts are broken, we will send new parts to repair after confirmed.
Q7: Can I order one piece for sample to test the quality?
A7: Yes, We recommend to check the sample before order. Please order the sample in our retail store.
Q8: May I have your catalogue and price list for trial order in MOQ quantity?
A8: All our products were shown on alibaba, please have a detailed looking and choose the interested models on our website.
Q9: how can you guarantee the price?
A9: we are not only trade company but manufacturing company,i am sure our price is better than other trade companies.
Q10: If I order big quantity, what's the good price?
A10: Please send the details enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Payment Terms, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible
latching solenoid valve
