- Place of Origin:CN;GUA
- Material:Stainless Steel
- Brand Name:COVNA solenoid valve for air compressed
- Model Number:HK41 solenoid valve for air compressed
- Power:Solenoid
- Pressure:High Pressure
- Application:General
- Port Size:1/4",3/8",1/2"
- Structure:Diaphragm
- Standard or Nonstandard:Standard
- Temperature of Media:High Temperature
- Media:hot water,compressed air,water,oil
{High pressure solenoid valve}
1/2'' High pressure solenoid valve 220v ac :
| Characteristic | High pressure Pilot operated piston construction with low power consumption | ||||||
| Seal serves long time at steam ambient | |||||||
| Used for long time working in pipeline systerm | |||||||
| Medium | Steam, hot water, oil | ||||||
| Temperature | PTFE seal:-40 to 200 degree | ||||||
| Pressure | 0.05Mpa to 1.6Mpa NC | ||||||
| Port size | 1/4",3/8",1/2" | ||||||
| Port thread | G, BSPP, NPT | ||||||
| orifice(mm) | 2.0,8.0,12.0 | ||||||
| Voltage | DC:12V, 24V, 36V | ||||||
| AC:24V, 120V, 240V/Hz; 110V, 220V/50Hz | |||||||
| Tolerance | +/-10% | ||||||
| Coils | Y21H,28VA(AC), 22W(DC), IP65, 100%ED | ||||||
| Material | Body: brass or stainless steel | ||||||
| Seal:PTFE | |||||||
| Armature tube:Stainless steel 304 | |||||||
| Plunger:stainless steel 430F | |||||||
| Stop:SS403F | |||||||
| Springs:SS304 | |||||||
| Shading rings:stainless steel 304 | |||||||
Warranty
1.1 year
2.Great quality valves
3.We stand behind the quality of our valves 100%
4.All of our valves come with a warranty to give you a peace of mind.
5.New Guaranteed: All of our valves are in new condition in OEM or Original packing.
Package
1. Neutral Package: Plastic Tube + Carton + plywood case/based
2. Commercial Package: Color Box + Carton + plywood case/based
3. As your requirements and order execution
Payment:
1) TT, 30% deposit , 70% before shippment.
2) L/C at sight. (high bank charge, not suggest , but acceptable )
3) 100% Western Union in advance. (specially for air shipment or small amount)
Q1: What is the Warranty for the solenoid valves?
A1: For the valves,we have one and half year warranty.If any quality problems on our side occured in this period ,we will make replacement.
Q2:What is NO and NC?
A2: NO stands for normally open, that is , valve keeps open without power.If connect it with power, the valve will get closed.NC stands for normally closed,that is valve keeps closed without power.If connect it with power, the valve will get open.
Q3: What is the assembly way of solenoid valves?
A.3 we suggest to make horizontal installation to enlarge life time,but it can be vertical installation if have special request.
Q4:Is there cheap shipping cost to import to our country?
A4: For small order,express will be best.And for bulk order,sea ship way is best but take much time. For urgent orders,we suggest to ship by air.
Q5:Can we make customized product?
A5: Yes, we are good at making customized products.More than 30% of our products are customized products. We have successfully customized for customer from various fields from USA,Norway.Australia, Germany ect.
Q6: Why choose us? Any advantages?
A6: The answer is Yes. There are5 advantages.
(1) MUTUAL BENEFIT: Our offer will be reasonable, our price will be cheaper in the same quality.
(2) CUSTOMIZED SERVICE: We can make the product as your request, Shape and Quality can meet your request.
(3) OEM: (1)Laser Print your Logo (≥10PCS). (2)Design your packing box(≥100PCS).
(4) MIX ORDER: We accept mix order, different model and small quantity order.
(5) AFTER SERVICE: (1)1.5Years Guarantee. (2)If some parts are broken, we will send new parts to repair after confirmed.
Q7: Can I order one piece for sample to test the quality?
A7: Yes, We recommend to check the sample before order. Please order the sample in our retail store.
Q8: May I have your catalogue and price list for trial order in MOQ quantity?
A8: All our products were shown on alibaba, please have a detailed looking and choose the interested models on our website.
Q9: how can you guarantee the price?
A9: we are not only trade company but manufacturing company,i am sure our price is better than other trade companies.
Q10: If I order big quantity, what's the good price?
A10: Please send the details enquiry to us, such as the Item Number, Quantity for each item, Quality request, Logo, Payment Terms, Transport method, Discharge place etc. We will make the accurate quotation to you as soon as possible
Company profile, Factory view and Office view
We specialize in developing,manufacturing and selling solenoid valve,pneumatic valve,electric valve,
pulse valve,valves,pneumatic components,solenoid valve accessory,pipeline accessory.
We have CE , RoHS ,the ISO9001,and TUV certificate.
